| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 5/130 in/mm |
| Depth | 4/100 in/mm |
| Net Weight | 2. 9 kgs |
| Shipping Weight(1 pc) | 3. 1 kgs |
| Shipping Box(1 pc) | 13. 5X13. 5X10. 5 cm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 2/50 in/mm |
| MAX Power | 200 Watts |
| RMS Power | 100 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 500-20k Hz |
| Sensitivity(1W/1m) | 110 dB |
| Voice Coil Diameter | 3″ / 74. 4mm |
| Winding material | CCAR |
| Magnet | Neodymium |
| Diaphragm material | Titanium diaphragm |
