| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 4.7/120 in/mm |
| Depth | 2.5/63 in/mm |
| Net Weight | 2. 2 kgs |
| Shipping Weight(1 pc) | 2. 3 kgs |
| Shipping Box(1 pc) | 13. 5X13X6. 7cm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 1/25 in/mm |
| MAX Power | 120 Watts |
| RMS Power | 60 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 1K Hz-18k Hz |
| Sensitivity(1W/1m) | 108.5 dB |
| Voice Coil Diameter | 1.75"/44.4mm |
| Windling material | CCAR |
| Magnet | 30 Oz |
| Diaphragm material | PEN diaphragm |
