| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 3.5/90 in/mm |
| Depth | 2/50 in/mm |
| Net Weight | 0. 9 kg |
| Shipping Weight(1 pc) | 1 kgs |
| Shipping Box(1 pc) | 9. 5X9. 5X7cm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 1/25 in/mm |
| MAX Power | 80 Watts |
| RMS Power | 40 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 1.5K Hz-18k Hz |
| Sensitivity(1W/1m) | 105 dB |
| Voice Coil Diameter | 1.35"/34.4mm |
| Windling material | CCAR |
| Magnet | 12 Oz |
| Diaphragm material | PEN diaphragm |
