| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 6.1/154 in/mm |
| Depth | 2. 1/54 in/mm |
| Net Weight | 3.3 kgs |
| Shipping Weight(1 pc) | 3. 4 kgs |
| Shipping Box(1 pc) | 16. 5X16.5X6. 5 cm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 1.5/38 in/mm |
| MAX Power | 240 Watts |
| RMS Power | 120 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 500 Hz-20k Hz |
| Sensitivity(1W/1m) | 108 dB |
| Voice Coil Diameter | 4″ / 99.2mm |
| Winding material | CCAR |
| Magnet | Neodymium |
| Diaphragm material | Titanium diaphragm |
