| NOMINAL SPECIFICATIONS | |
| Throat Diameter | 1'/25 in/mm |
| MAX Power | 40 Watts |
| RMS Power | 20 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 3 kHZ-20 kHZ |
| Sensitivity(1W/1m) | 100 dB |
| Voice Coil Diameter | 1''/25 mm |
| Windling material | CCAR(Aluminum) |
| Magnet | 14 OZ |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 4.1/105 in/mm |
| Depth | 2.1/55 in/mm |
| Net Weight | 0.7 kgs |
| Shipping Weight(1 pc) | 0.8 kgs |
| Shipping Box（1 pc） | 9.5X9.5X7cm |
