| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 6.7/170 in/mm |
| Depth | 2. 7/68 in/mm |
| Net Weight | 4.0 kgs |
| Shipping Weight(1 pc) | 4. 2 kgs |
| Shipping Box(1 pc) | 19X18X7.5 cm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 2/50 in/mm |
| MAX Power | 200 Watts |
| RMS Power | 100 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 800-18k Hz |
| Sensitivity(1W/1m) | 108 dB |
| Voice Coil Diameter | 3″ / 74.4mm |
| Winding material | CCAR |
| Magnet | 60 Oz |
| Diaphragm material | Titanium diaphragm |
