| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 8/205 in/mm |
| MAX Power | 400 Watts |
| RMS Power | 200 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) | Frequency |
| Frequency Response | 224-7000 Hz |
| Sensitivity(1W/1m) | 98 dB |
| Voice Coil Diameter | 3"/75 mm |
| Windling material | PICCAW (inside-outside) |
| Magnet | Neodymium |
| MOUNTING/SHIPPING INFORMATION | ||
| Overall Diameter | 9.4/240 in/mm | |
| Bolt Circle Diameter | 8.8/223 in/mm | |
| Baffle cutout Diameter | 7.9/200 in/mm | |
| Depth | 4.6/117 in/mm | |
| Net Weight | 4.4 kgs | |
| Shipping Weight | 4.8 kgs | |
| Shipping Box | 23.5X23.5X13. 5 cm | |
| THIELE SMALL PARAMETERS | |
| FS Hz | 224 Hz |
| Vas | 1.2 cm³ |
| RE Ohms | 5.1 ohm |
| Qms | 23 |
| Qes | 0.69 |
| Qts | 0.67 |
| BLT/m | 18 T/m |
| MMS(grms) | 26 grams |
| Xmax(mm) | 3.1 mm |
| Sd(cm²) | 220 cm² |
| Efficiency % | 2.0 % |
| EBP | 324 |
