| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 8/205 in/mm |
| MAX Power | 400 Watts |
| RMS Power | 200 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 75 Hz |
| Frequency Response | 75-18000 Hz |
| Sensitivity(1W/1m) | 95 dB |
| Voice Coil Diameter | 2.4"/60.6mm |
| Windling material | KCCAW |
| Magnet | 54 Oz 156*70*20mm |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 8/212 in/mm |
| Baffle cutout Diameter | 7 /188 in/mm |
| Depth | 5.3/135 in/mm |
| Net Weight | 4. 25 kgs |
| Shipping Weight | 5 kgs |
| Shipping Box | 23. 5X23.5X17cm |
| DRIVER SPECIFICATIONS | |
| Impedance | 8 Ohm |
| Frequency Response | 1k-18k Hz |
| Sensitivity(1W/1m) | 104 dB |
| Voice Coil Diameter | 1.75"/44.4mm |
| Windling material | CCAR |
| Diaphragm Material | PEI |
| THIELE SMALL PARAMETERS | |
| FS Hz | 75 Hz |
| Vas | 8. 2 dm³ |
| RE Ohms | 5. 4 ohm |
| Qms | 7. 4 |
| Qes | 0. 5 |
| Qts | 0. 47 |
| BLT/m | 8. 5 T/m |
| MMS(grms) | 14 grams |
| Sd(cm²) | 214 cm² |
| Efficiency % | 1. 5 % |
| Le(1k Hz) | 0. 2 mH |
| EBP | 150 |
