| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 7.28 /185 in/mm |
| Depth | 3.43 /87 in/mm |
| Net Weight | 6. 25 kgs |
| Shipping Weight(1 pc) | 6. 35 kgs |
| Shipping Box(1 pc) | 200X185X100 mm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 2/50 in/mm |
| MAX Power | 240 Watts |
| RMS Power | 120 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 500-17k Hz |
| Sensitivity(1W/1m) | 109 dB |
| Voice Coil Diameter | 3″ / 74.4mm |
| Windling material | CCAR |
| Magnet | 70 Oz |
