| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 21/550 in/mm |
| MAX Power | 6000 Watts |
| RMS Power | 3000 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 35 Hz |
| Frequency Response | 35-1000 Hz |
| Sensitivity(1W/1m) | 98 dB |
| Voice Coil Diameter | 6"/152.3mm |
| Windling material | GPI(inside-outside) |
| Magnet | Neodymium |
| MOUNTING/SHIPPING INFORMATION | ||
| Overall Diameter | 21. 6/550 in/mm | |
| Bolt Circle Diameter | 20.5/522 in/mm | |
| Baffle cutout Diameter | 19.5/498 in/mm | |
| Depth | 10.4/265 in/mm | |
| Net Weight | 19. 7 kgs | |
| Shipping Weight | 21 kgs | |
| Shipping Box | 60X60X32.5cm | |
| THIELE SMALL PARAMETERS | |
| FS Hz | 35 Hz |
| Vas | 219 dm³ |
| RE Ohms | 5. 4 ohm |
| Qms | 16 |
| Qes | 0. 34 |
| Qts | 0. 33 |
| BLT/m | 30 T/m |
| MMS(grms) | 364 grams |
| Xmax(mm) | 14. 8 mm |
| Sd(cm²) | 1600 cm² |
| Efficiency % | 2% |
| Le(1k Hz) | 1. 9 mH |
| EBP | 103 |
