| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 18/460 in/mm |
| MAX Power | 2000 Watts |
| RMS Power | 1000 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 30 Hz |
| Frequency Response | 30-1500 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4"/100mm |
| Windling material | GEI(inside-outside) |
| Magnet | 125 Oz 220*110*25mm |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 18/462 in/mm |
| Bolt Circle Diameter | 17.6/450 in/mm |
| Baffle cutout Diameter | 16.4/418 in/mm |
| Depth | 8.7/222 in/mm |
| Net Weight | 12. 55 kgs |
| Shipping Weight | 13.55 kgs |
| Shipping Box | 49.5X49.5X25. 5cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 30 Hz |
| Vas | 329 dm³ |
| RE Ohms | 6. 2 ohm |
| Qms | 7. 3 |
| Qes | 0. 30 |
| Qts | 0. 29 |
| BLT/m | 24 T/m |
| MMS(grms) | 155 grams |
| Xmax(mm) | 4. 4 mm |
| Sd | 1100 cm² |
| Efficiency % | 2. 9% |
| EBP | 100 |
