| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 18/460 in/mm |
| MAX Power | 2400 Watts |
| RMS Power | 1200 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 32 Hz |
| Frequency Response | 32-3000 Hz |
| Sensitivity(1W/1m) | 98 dB |
| Voice Coil Diameter | 4''/100mm |
| Voice Coil Material | GPI(inside-outside) |
| Magnet | Neodymium |
|
| |
| THIELE & SMALL PARAMETERS | |
| FS | 32 Hz |
| RE | 5.6 ohm |
| Qms | 12.5 |
| Qes | 0.3 |
| Qts | 0.29 |
| BL | 27 T/m |
| MMS | 202 grams |
| Xmax | 11 mm |
| Sd | 1190 cm² |
| Efficiency | 2.15% |
| Le(1k Hz) | 0.57mH |
| EBP | 110 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 18.1 /460 in/mm |
| Bolt Circle Diameter | 17.3/439 in/mm |
| Baffle cutout Diameter | 16.5 /418 in/mm |
| Depth | 8.2 /210 in/mm |
| Net Weight | 7.65 kgs |
| Shipping Weight | 8.65 kgs |
| Shipping Box | 49.5X49.5X23cm |
