| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 15/385 in/mm |
| MAX Power | 3000 Watts |
| RMS Power | 1500 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 55 Hz |
| Frequency Response | 55-2000 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4.5″/114mm |
| Winding material | GPICCAW(inside-outside) |
| Magnet | 200 Oz 254*127*30 mm |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 15.5/395 in/mm |
| Bolt Circle Diameter | 14.8/375 in/mm |
| Baffle cutout Diameter | 14/355 in/mm |
| Depth | 7.3/185 in/mm |
| Net Weight | 18. 3 kgs |
| Shipping Weight | 20 kgs |
| Shipping Box | 41X41X20 cm |
| THIELE SMALL PARAMETERS | |
| FS | 55 Hz |
| Vas | 62 L |
| RE | 5.4 Ohm |
| Qms | 8.6 |
| Qes | 0.47 |
| Qts | 0.44 |
| BL | 25 T•m |
| MMS(grms) | 125 grams |
| Xmax(mm) | 11.2 mm |
| Sd | 855 cm2 |
| Eficiency% | 2.40% |
| EBP | 117 |
