| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 15/385 in/mm |
| MAX Power | 2400 Watts |
| RMS Power | 1200 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 36 Hz |
| Frequency Response | 36-2000 Hz |
| Sensitivity(1W/1m) | 98 dB |
| Voice Coil Diameter | 4"/100mm |
| Windling material | GPICCAW(inside-outside) |
| Magnet | 150 Oz 220*110*30mm |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 15.5/395 in/mm |
| Bolt Circle Diameter | 14.7/375 in/mm |
| Baffle cutout Diameter | 13.9/355 in/mm |
| Depth | 7.6/195 in/mm |
| Net Weight | 13. 9 kgs |
| Shipping Weight | 14.9 kgs |
| Shipping Box | 41X41X23cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 36 Hz |
| Vas | 125 dm³ |
| RE Ohms | 5. 6 ohm |
| Qms | 7. 5 |
| Qes | 0. 48 |
| Qts | 0. 45 |
| BLT/m | 25 T/m |
| MMS(grms) | 155 grams |
| Xmax(mm) | 14mm |
| Sd | 850 cm² |
| Efficiency % | 2. 0 % |
| EBP | 75 |
