| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 15/385 in/mm |
| MAX Power | 3000 Watts |
| RMS Power | 1500 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 43 Hz |
| Frequency Response | 43-1500 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4. 5"/114mm |
| Windling material | GPI(inside-outside) |
| Magnet | Neodymium |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 15.2/394 in/mm |
| Bolt Circle Diameter | 14. 77/375 in/mm |
| Baffle cutout Diameter | 14. 1 /356 in/mm |
| Depth | 7. 17 /182 in/mm |
| Net Weight | 10. 7 kgs |
| Shipping Weight | 11.65 kgs |
| Shipping Box | 41. 5X41.5X25cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 43 Hz |
| Vas | 73 dm³ |
| RE Ohms | 5.2 ohm |
| Qms | 7.2 |
| Qes | 0. 29 |
| Qts | 0.28 |
| BLT/m | 29 T/m |
| MMS(grms) | 183 grams |
| Xmax(mm) | 11.2 mm |
| Sd(cm²) | 850 cm² |
| Efficiency % | 2.50% |
| EBP | 148 |
