| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 15/380 in/mm |
| MAX Power | 700 Watts |
| RMS Power | 350 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 57 Hz |
| Frequency Response | 57-4000 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4''/100mm |
| Voice Coil Material | GSV(inside-outside) |
| Magnet | Neodymium |
|
| |
| THIELE & SMALL PARAMETERS | |
| FS | 57 Hz |
| RE | 6.2 ohm |
| Qms | 5 |
| Qes | 0.49 |
| Qts | 0.44 |
| BL | 22 T/m |
| MMS | 109 grams |
| Xmax | 3.8 mm |
| Sd | 897 cm² |
| Efficiency | 2.9% |
| Le(1k Hz) | 0.2 mH |
| EBP | 129 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 15.5 /395 in/mm |
| Bolt Circle Diameter | 14.7/374 in/mm |
| Baffle cutout Diameter | 13.8 /350 in/mm |
| Depth | 7 /178 in/mm |
| Net Weight | 5.35 kgs |
| Shipping Weight | 6.35 kgs |
| Shipping Box | 41X41X20cm |
