| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 15/385 in/mm |
| MAX Power | 1500 Watts |
| RMS Power | 750 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 41 Hz |
| Frequency Response | 41-2500 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4''/100mm |
| Voice Coil Material | GPI(inside-outside) |
| Magnet | Neodymium |
| THIELE & SMALL PARAMETERS | |
| FS | 41 Hz |
| RE | 5.6 ohm |
| Qms | 14 |
| Qes | 0.37 |
| Qts | 0.36 |
| BL | 24 T/m |
| MMS | 153 grams |
| Xmax | 11.2 mm |
| Sd | 819 cm² |
| Efficiency | 1.6% |
| Le(1k Hz) | 0.6mH |
| EBP | 113 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 15.52 /394 in/mm |
| Bolt Circle Diameter | 13.9/378 in/mm |
| Baffle cutout Diameter | 6.26 /356 in/mm |
| Depth | 6.89 /175 in/mm |
| Net Weight | 6.6 kgs |
| Shipping Weight | 7.4 kgs |
| Shipping Box | 41X41X20.5cm |
