| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 15/380 in/mm |
| MAX Power | 1200 Watts |
| RMS Power | 600 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 35 Hz |
| Frequency Response | 35-2000 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4''/100mm |
| Voice Coil Material | GSV(inside-outside) |
| Magnet | Neodymium |
| THIELE & SMALL PARAMETERS | |
| FS | 35Hz |
| RE | 5.4 ohm |
| Qms | 12 |
| Qes | 0.3 |
| Qts | 0.29 |
| BL | 22 T/m |
| MMS | 123 grams |
| Xmax | 10 mm |
| Sd | 855 cm² |
| Efficiency | 2.3% |
| Le(1k Hz) | 1.8 mH |
| EBP | 116 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 15.5 /395 in/mm |
| Bolt Circle Diameter | 14.8/376 in/mm |
| Baffle cutout Diameter | 14.1 /359 in/mm |
| Depth | 6.7 /170 in/mm |
| Net Weight | 7.8 kgs |
| Shipping Weight | 8.8 kgs |
| Shipping Box | 42X42X21cm |
