| ELECTRO ACOUSTIC SPECIFICATIONS | ||
| Nominal Chassis Diameter | 15''/385 in/mm | |
| MAX Power | 2400 Watts | |
| RMS Power | 1200 Watts | |
| Impedance | 8 Ohm | |
| Resonance(natural) Frequency | 45 Hz | |
| Frequency Response | 45-1200 Hz | |
| Sensitivity(1W/1m) | 97 dB | |
| Voice Coil Diameter | 4.5''/ 114mm | |
| Winding material | PI(inside-outside) | |
| Magnet | 201 Oz 254x127x30mm | |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 15.5/393 in/mm |
| Bolt Circle Diameter | 14/357 in/mm |
| Baffle cutout Diameter | 13.9/353 in/mm |
| Depth | 7.9/200 in/mm |
| Net Weight | 18 kgs |
| Shipping Weight | 19 kgs |
| Shipping Box | 40.5x40.5x23 cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 45 Hz |
| Vas | 45 dm³ |
| RE Ohms | 5.2 ohm |
| Qms | 15.7 |
| Qes | 0.4 |
| Qts | 0.39 |
| BL T/m | 31 T/m |
| MMS(grms) | 250 grams |
| Xmax(mm) | 15 mm |
| Sd | 829 cm² |
| Efficiency % | 2.5 % |
| EBP | 112 |
