| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 15/380 in/mm |
| MAX Power | 900 Watts |
| RMS Power | 450 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 45 Hz |
| Frequency Response | 45-4000 Hz |
| Sensitivity(1W/1m) | 98 dB |
| Voice Coil Diameter | 3''/75mm |
| Voice Coil Material | GSV(inside-outside) |
| Magnet | 80OZ |
| THIELE & SMALL PARAMETERS | |
| FS | 45 Hz |
| RE | 5.4 ohm |
| Qms | 4 |
| Qes | 0.44 |
| Qts | 0.43 |
| BL | 18 T/m |
| MMS | 88 grams |
| Xmax | 6.5 mm |
| Sd | 897 cm² |
| Efficiency | 2.7% |
| Le(1k Hz) | 0.2mH |
| EBP | 104Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 15.2/390 in/mm |
| Bolt Circle Diameter | 14.5/372 in/mm |
| Baffle cutout Diameter | 13.8 /355 in/mm |
| Depth | 7.25 /185 in/mm |
| Net Weight | 7.4 kgs |
| Shipping Weight | 8.4 kgs |
| Shipping Box | 40.5X40.5X20.5cm |
