| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 12/300 in/mm |
| MAX Power | 1200 Watts |
| RMS Power | 600 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 59 Hz |
| Frequency Response | 59-2500 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4''/100mm |
| Voice Coil Material | GPI(inside-outside) |
| Magnet | 125 Oz |
| THIELE & SMALL PARAMETERS | |
| FS | 59 Hz |
| RE | 6.2 ohm |
| Qms | 5.6 |
| Qes | 0.23 |
| Qts | 0.22 |
| BL | 27 T/m |
| MMS | 76 grams |
| Xmax | 6 mm |
| Sd | 531 cm² |
| Efficiency | 3.2% |
| Le(1k Hz) | 1.7 mH |
| EBP | 268 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 12.7 /325 in/mm |
| Bolt Circle Diameter | 11.6/295 in/mm |
| Baffle cutout Diameter | 11.2 /287 in/mm |
| Depth | 6.3 /160 in/mm |
| Net Weight | 11.6 kgs |
| Shipping Weight | 12.6 kgs |
| Shipping Box | 33.5X33.5X18cm |
