| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 12/300 in/mm |
| MAX Power | 600 Watts |
| RMS Power | 300 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 50 Hz |
| Frequency Response | 50-4000 Hz |
| Sensitivity(1W/1m) | 98 dB |
| Voice Coil Diameter | 3”/75mm |
| Voice Coil Material | GPI(inside-outside) |
| Magnet | Neodymium |
| THIELE & SMALL PARAMETERS | |
| FS | 50 Hz |
| RE | 6.2 ohm |
| Qms | 9.9 |
| Qes | 0.22 |
| Qts | 0.21 |
| BL | 20 T/m |
| MMS | 45 grams |
| Xmax | 2.1 mm |
| Sd | 531 cm² |
| Efficiency | 4.70% |
| Le(1k Hz) | 0.11mH |
| EBP | 238 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 12.4 /315 in/mm |
| Bolt Circle Diameter | 11.8/300 in/mm |
| Baffle cutout Diameter | 11.1 /283 in/mm |
| Depth | 5.7 /145 in/mm |
| Net Weight | 5.1 kgs |
| Shipping Weight | 6.1 kgs |
| Shipping Box | 33.5X33.5X17cm |
