| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 10/250 in/mm |
| MAX Power | 600 Watts |
| RMS Power | 300 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 55 Hz |
| Frequency Response | 55-4500 Hz |
| Sensitivity(1W/1m) | 96 dB |
| Voice Coil Diameter | 2.5”/65mm |
| Voice Coil Material | KSV(inside-outside) |
| Magnet | Neodymium |
| THIELE & SMALL PARAMETERS | |
| FS | 55 Hz |
| RE | 5.4 ohm |
| Qms | 5 |
| Qes | 0.28 |
| Qts | 0.27 |
| BL | 15 T/m |
| MMS | 34 grams |
| Xmax | 4 mm |
| Sd | 353 cm² |
| Efficiency % | 2.3% |
| Le(1k Hz) | 1.3 mH |
| EBP | 196 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 10.4 /263 in/mm |
| Bolt Circle Diameter | 9.7/247 in/mm |
| Baffle cutout Diameter | 9.2 /233 in/mm |
| Depth | 5.3 /135 in/mm |
| Net Weight | 2.65 kgs |
| Shipping Weight | 3.2 kgs |
| Shipping Box | 28.5X28.5X19cm |
