| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 10/254 in/mm |
| MAX Power | 600 Watts |
| RMS Power | 300 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 268 Hz |
| Frequency Response | 268-5500 Hz |
| Sensitivity(1W/1m) | 99 dB |
| Voice Coil Diameter | 3″/75. 5mm |
| Windling material | GPICCAW (inside-outside) |
| Magnet | Neodymium |
| MOUNTING/SHIPPING INFORMATION | ||
| Overall Diameter | 10. 2/260 in/mm | |
| Bolt Circle Diameter | 10.8/274 in/mm | |
| Baffle cutout Diameter | 9.1/232 in/mm | |
| Depth | 5.1/130 in/mm | |
| Net Weight | 4. 4 kgs | |
| Shipping Weight | 4.8 kgs | |
| Shipping Box | 30X27.5X15cm | |
| THIELE SMALL PARAMETERS | |
| FS Hz | 268 Hz |
| Vas | 3 dm³ |
| RE Ohms | 5. 1 ohm |
| Qms | 9. 2 |
| Qes | 0. 85 |
| Qts | 0. 78 |
| BLT/m | 21 T/m |
| MMS(grms) | 21 grams |
| Xmax(mm) | 2. 1mm |
| Sd(cm²) | 360 cm² |
| Efficiency % | 6. 6 % |
| EBP | 315 |
