| ELECTRO ACOUSTIC SPECIFICATIONS | ||
| Nominal Chassis Diameter | 15/385 in/mm | |
| MAX Power | 2400 Watts | |
| RMS Power | 1200 Watts | |
| Impedance | 8 Ohm | |
| Resonance(natural) Frequency | 45 Hz | |
| Frequency Response | 45-2500 Hz | |
| Sensitivity(1W/1m) | 97 dB | |
| Voice Coil Diameter | 4''/ 100mm | |
| Winding material | PICCAW(inside-outside) | |
| Magnet | Neodymium | |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 15.5x16/398x405 in/mm |
| Bolt Circle Diameter | 14.6x370 in/mm |
| Baffle cutout Diameter | 14.2x360 in/mm |
| Depth | 7.5/192 in/mm |
| Net Weight | 8.4 kgs |
| Shipping Weight | 8.7 kgs |
| Shipping Box | 41.5x41.5x25 cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 45 Hz |
| Vas | 86 dm³ |
| RE Ohms | 4.6 ohm |
| Qms | 6.46 |
| Qes | 0.51 |
| Qts | 0.47 |
| BL T/m | 19.4 T/m |
| MMS(grms) | 147 grams |
| Xmax(mm) | 147 mm |
| Sd | 855 cm² |
| Efficiency % | 1.49 % |
| EBP | 88 |
