| ELECTRO ACOUSTIC SPECIFICATIONS | ||
| Nominal Chassis Diameter | 19/480 in/mm | |
| MAX Power | 3000 Watts | |
| RMS Power | 1500 Watts | |
| Impedance | 8 Ohm | |
| Resonance(natural) Frequency | 27 Hz | |
| Frequency Response | 27-1200 Hz | |
| Sensitivity(1W/1m) | 98 dB | |
| Voice Coil Diameter | 4''/ 100mm | |
| Winding material | GEI(inside-outside) | |
| Magnet | Neodymium | |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 18.9/480 in/mm |
| Bolt Circle Diameter | 18.1/460 in/mm |
| Baffle cutout Diameter | 17.5/446 in/mm |
| Depth | 10/255 in/mm |
| Net Weight | 10 kgs |
| Shipping Weight | 11 kgs |
| Shipping Box | 52x52x30 cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 27 Hz |
| Vas | 224 dm³ |
| RE Ohms | 4.7 ohm |
| Qms | 13 |
| Qes | 0.27 |
| Qts | 0.26 |
| BL T/m | 32 T/m |
| MMS(grms) | 360 grams |
| Xmax(mm) | 19.3 mm |
| Sd | 1307 cm² |
| Efficiency % | 1.5 % |
| EBP | 100 |
