| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 7. 6/170 in/mm |
| Depth | 8. 2/80 in/mm |
| Net Weight | 4.5 kgs |
| Shipping Weight(1 pc) | 4. 7 kgs |
| Shipping Box(1 pc) | 19X18X9. 5cm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 2/50 in/mm |
| MAX Power | 200 Watts |
| RMS Power | 100 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 800Hz -18k Hz |
| Sensitivity(1W/1m) | 108 dB |
| Voice Coil Diameter | 2. 84"/72.2mm |
| Windling material | CCAW |
| Magnet | 62 Oz |
| Diaphragm material | Titanium diaphragm |
