| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 1/25 in/mm |
| MAX Power | 80 Watts |
| RMS Power | 40 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 800-10k HZ |
| Sensitivity(1W/1m) | 100 dB |
| Voice Coil Diameter | 1.75” / 44.4 mm |
| Windling material | CCAW(Aluminium) |
| Magnet | 34 Oz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 4/101 in/mm |
| Depth | 3/74 in/mm |
| Net Weight | 1.35 kgs |
| Shipping Weight(1 pc) | 1.5 kgs |
| Shipping Box（1 pc） | 11X11X8.7 cm |
