| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 6.1/156 in/mm |
| Depth | 2.5/65 in/mm |
| Net Weight | 3.5 kgs |
| Shipping Weight(1 pc) | 3. 7 kgs |
| Shipping Box(1 pc) | 17X16X7cm |
| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Throat Diameter | 2/50 in/mm |
| MAX Power | 220 Watts |
| RMS Power | 110 Watts |
| Impedance | 8 Ohm |
| Frequency Response | 1K Hz-18k Hz |
| Sensitivity(1W/1m) | 107 dB |
| Voice Coil Diameter | 3"/74.4mm |
| Windling material | CCAR |
| Magnet | 50 Oz |
| Diaphragm material | Titanium diaphragm |
