| ELECTRO ACOUSTIC SPECIFICATIONS | ||
| Nominal Chassis Diameter | 18/460 in/mm | |
| MAX Power | 2400 Watts | |
| RMS Power | 1200 Watts | |
| Impedance | 8 Ohm | |
| Resonance(natural) Frequency | 29 Hz | |
| Frequency Response | 29-2500 Hz | |
| Sensitivity(1W/1m) | 96 dB | |
| Voice Coil Diameter | 4''/ 100mm | |
| Winding material | PI (inside-outside) | |
| Magnet | Neodymium | |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 18.1/460 in/mm |
| Bolt Circle Diameter | 17.5/444 in/mm |
| Baffle cutout Diameter | 16.4/416 in/mm |
| Depth | 9.0/230 in/mm |
| Net Weight | 10 kgs |
| Shipping Weight | 11 kgs |
| Shipping Box | 49.5x49.5x26 cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 29 Hz |
| Vas | 270 dm³ |
| RE Ohms | 5.2 ohm |
| Qms | 9 |
| Qes | 0.38 |
| Qts | 0.35 |
| BL T/m | 24 T/m |
| MMS(grms) | 195 grams |
| Xmax(mm) | 13.5 mm |
| Sd | 120 cm² |
| Efficiency % | 2.1 % |
| EBP | 76 |
