| ELECTRO ACOUSTIC SPECIFICATIONS | ||
| Nominal Chassis Diameter | 12/205 in/mm | |
| MAX Power | 1600 Watts | |
| RMS Power | 800 Watts | |
| Impedance | 8 Ohm | |
| Resonance(natural) Frequency | 56 Hz | |
| Frequency Response | 56-3200 Hz | |
| Sensitivity(1W/1m) | 97 dB | |
| Voice Coil Diameter | 3.5''/ 89mm | |
| Winding material | ALR | |
| Magnet | Neodymium | |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 12.4/317 in/mm |
| Bolt Circle Diameter | 11.8/300 in/mm |
| Baffle cutout Diameter | 11.2/285 in/mm |
| Depth | 6.1/155 in/mm |
| Net Weight | 4.5 kgs |
| Shipping Weight | 5 kgs |
| Shipping Box | 33.5x33.5x17 cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 56 Hz |
| Vas | 55 dm³ |
| RE Ohms | 5.4 ohm |
| Qms | 9 |
| Qes | 0.26 |
| Qts | 0.25 |
| BL T/m | 20 T/m |
| MMS(grms) | 57 grams |
| Xmax(mm) | 4.7 mm |
| Sd | 500 cm² |
| Efficiency % | 3.5 % |
| EBP | 215 |
