| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 12/305 in/mm |
| MAX Power | 1200 Watts |
| RMS Power | 600 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 59 Hz |
| Frequency Response | 59-4000 Hz |
| Sensitivity(1W/1m) | 98 dB |
| Voice Coil Diameter | 3"/75. 5mm |
| Windling material | GPICCAW(inside-outside) |
| Magnet | Neodymium |
| MOUNTING/SHIPPING INFORMATION | ||
| Overall Diameter | 12/316 in/mm | |
| Bolt Circle Diameter | 11.7/300 in/mm | |
| Baffle cutout Diameter | 11/284 in/mm | |
| Depth | 6/155 in/mm | |
| Net Weight | 4. 7 kgs | |
| Shipping Weight | 5.3 kgs | |
| Shipping Box | 33.5X33.5X17cm | |
| THIELE SMALL PARAMETERS | |
| FS Hz | 59 Hz |
| Vas | 55 dm³ |
| RE Ohms | 5. 1 ohm |
| Qms | 4. 5 |
| Qes | 0. 38 |
| Qts | 0. 35 |
| BLT/m | 19 T/m |
| MMS(grms) | 51 grams |
| Xmax(mm) | 5. 7 mm |
| Sd | 530 cm² |
| Efficiency % | 3. 2% |
| EBP | 155 |
