| ELECTRO ACOUSTIC SPECIFICATIONS | ||
| Nominal Chassis Diameter | 10/254 in/mm | |
| MAX Power | 1200 Watts | |
| RMS Power | 600 Watts | |
| Impedance | 8 Ohm | |
| Resonance(natural) Frequency | 69 Hz | |
| Frequency Response | 69-4000 Hz | |
| Sensitivity(1W/1m) | 97 dB | |
| Voice Coil Diameter | 3.5''/ 89mm | |
| Winding material | ALR | |
| Magnet | Neodymium | |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 10.4/265 in/mm |
| Bolt Circle Diameter | 9.6/245 in/mm |
| Baffle cutout Diameter | 9/228 in/mm |
| Depth | 5.7/145 in/mm |
| Net Weight | 4.2 kgs |
| Shipping Weight | 4.8 kgs |
| Shipping Box | 29x29x16 cm |
| THIELE SMALL PARAMETERS | |
| FS Hz | 50 Hz |
| Vas | 140 dm³ |
| RE Ohms | 5.4 ohm |
| Qms | 8.2 |
| Qes | 0.35 |
| Qts | 0.34 |
| BL T/m | 19 T/m |
| MMS(grms) | 79 grams |
| Xmax(mm) | 5.7 mm |
| Sd | 800 cm² |
| Efficiency % | 4.6 % |
| EBP | 143 |
