| NOMINAL SPECIFICATIONS | |
| Nominal Diameter | 18/460 in/mm |
| MAX Power | 2000 Watts |
| RMS Power | 1000 Watts |
| Impedance | 8 Ohm |
| Resonance Frequency | 35 Hz |
| Frequency Response | 35-1500 Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 4''/100mm |
| Voice Coil Material | GPI(inside-outside) |
| Magnet | 150 Oz |
| THIELE & SMALL PARAMETERS | |
| FS | 35 Hz |
| RE | 5.2 ohm |
| Qms | 6.95 |
| Qes | 0.4 |
| Qts | 0.39 |
| BL | 24 T/m |
| MMS | 215 grams |
| Xmax | 6 mm |
| Sd | 1244 cm² |
| Efficiency | 2.1% |
| Le(1k Hz) | 2 mH |
| EBP | 90 Hz |
| MOUNTING AND SHIPPING INFORMATION | |
| Overall Diameter | 19.1 /488 in/mm |
| Bolt Circle Diameter | 18.2/465 in/mm |
| Baffle cutout Diameter | 16.5 /420 in/mm |
| Depth | 9 /230 in/mm |
| Net Weight | 13.7 kgs |
| Shipping Weight | 14.7 kgs |
| Shipping Box | 49.5X49.5X25cm |
