| ELECTRO ACOUSTIC SPECIFICATIONS | |
| Nominal Chassis Diameter | 10/254 in/mm |
| MAX Power | 500 Watts |
| RMS Power | 250 Watts |
| Impedance | 8 Ohm |
| Resonance(natural) Frequency | 51 Hz |
| Frequency Response | 51-18000 Hz |
| Sensitivity(1W/1m) | 95 dB |
| Voice Coil Diameter | 2.4"/60. 6mm |
| Windling material | GPI(inside-outside) |
| Magnet | 54 Oz 156*70*20mm |
| MOUNTING/SHIPPING INFORMATION | |
| Overall Diameter | 10/260 in/mm |
| Baffle cutout Diameter | 9 /230 in/mm |
| Depth | 6/152in/mm |
| Net Weight | 4. 85 kgs |
| Shipping Weight | 5. 5 kgs |
| Shipping Box | 28. 5X28. 5X18CM |
| DRIVER SPECIFICATIONS | |
| Impedance | 8 Ohm |
| Frequency Response | 1k-18K Hz |
| Sensitivity(1W/1m) | 100 dB |
| Voice Coil Diameter | 1. 7"/44. 4mm |
| Windling material | KCCAR |
| Diaphragm Material | PEI |
| THIELE SMALL PARAMETERS | |
| FS Hz | 51 Hz |
| Vas | 47. 4 dm³ |
| RE Ohms | 5. 4 ohm |
| Qms | 9. 3 |
| Qes | 0. 43 |
| Qts | 0. 41 |
| BLT/m | 11. 6 T/m |
| MMS(grms) | 32. 7 grams |
| Sd | 340 cm² |
| Efficiency % | 1. 5 % |
| Xmax | 4. 1 |
| EBP | 118 |
